✓ Basic Parameters
✓ Module: Module-Box 210CE
✓ External Dimensions: 5460 mm x 2000 mm x 2400 mm (L * W * H)
✓ Internal Dimensions: 5100 mm x 750 mm x 2100 mm (L * W * H)
✓ Rated Current: 4000 W (+10%) * 210 units
✓ Overall Color: White
✓ Weight: 1.9 T (-5% ~ +5 °/O)
✓ Electrical Appliance Certification: CE-CUL

Features

Maximum rated load：900kw/h
Fuse protection：125A*20 sets
Three-phase equilibrium：Each PDU is a sine wave with the same frequency, amplitude and phase difference of 120 degrees.
Current protection: When the current flowing through the protected parts exceeds a pre-set value, the protection device starts and uses the time limit to ensure the selectivity of the action, so that the circuit breaker trips or gives an alarm signal.

Function

✔ Loss of voltage protection: When the power is suddenly cut off due to some external reasons, the power can be cut off automatically;

✔ Phase loss protection: When one phase of the three-phase power supply is disconnected, the three-phase equipment will reduce the output power and cannot work normally, or cause accidents. Therefore, some important equipment need to add phase loss protection device.

✔ Undervoltage protection: refers to the action of the protection appliance when the line voltage is reduced to the critical level, and its task is mainly to prevent the equipment from burning up due to overload.

✔ Automatic reclosing switch：It is a device that automatically re-closes the circuit breaker after it has been separated due to a fault, using a mechanical device or relay automatic device.

Remote System

✔ Global remote control, custom on/off schedule.
✔ Custom socket power usage record inquiry.
✔ Overall safety certification by China Classification Society.
✔ Overall CE certification/cUL safety certification.
✔ The power supply network is isolated from the miner network, eliminating background fee collection.
